Phone Customization

129

For T58V/T58A/T56A:

Topics

Supported Programmable Keys

Programmable Keys Configuration

Supported Programmable Keys

The following tables list programmable keys for each phone model.

Programmable Key IDs T58V/T58A/T56A CP960

1 SoftKey1 SoftKey1

2 SoftKey2 SoftKey2

3 SoftKey3 SoftKey3
