Chapter 3 PERFORMING MEASUREMENTS
3-14
Changing the Measurement Condition Auto Setting
To simplify operation, the instrument provides a function that allows it to check the state of
the optical fiber at the start of measurement and set the following measurement conditions
automatically.
• Distance range
• Pulse width
• Attenuation
This measurement condition auto setting can be changed as explained below.
♦ Example: “OFF” → “AUTO RANGE”
1. Locate the cursor to “AUTO SET” by using the rotary knob or the arrow key.
2. Press [ENTER].
A selection window will appear.
*: Indicates the default setting.
TIP
OFF Performs measurement using the preset distance
range, pulse width and attenuation.
*AUTO RANGE Sets distance range, pulse width and attenuation
automatically at the start of measurement.
Selectable
auto setting
AUTO ATTN Sets attenuation automatically at the start of
measurement.
To Next Page
