YOKOGAWA AQ7260 OTDR

Chapter 3 PERFORMING MEASUREMENTS
3-75
5. Press [F2] (
2
).
“
2
” will appear at the cursor position.
The distance between the two points will be displayed.
Inter-marker information
SPLICE LOSS : dB
RETURN LOSS :
1
-
2
[a] dB
[b] km
[a] / [b] dB/km
2
-
3
dB
km
dB/km
1
2
[a]
[b]
Distance from the origin to
2
Distance between the two points
