Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-52
Device Message
No. Function
Header
Numeric
Part
Description
5-18 Auto search event
count output
SPPR Requests the number of events detected by auto
search.
(R point is included, END point is not included)
XXX
5-19 Auto search result
output
SPDR Requests the auto search results.
For the return value format, refer to page 8-60.
5-20 Section analysis start
point setting
SSPOSR Requests the section start position.
SXXXX.XXXXXTT
“S” indicates a sign.
“TT” indicates the distance unit.
5-21 Section analysis end
point setting
SEPOSR Requests the section end position.
SXXXX.XXXXXTT
“S” indicates a sign.
“TT” indicates the distance unit.
5-22 Reference return
loss setting
AJPOSR Requests the reference value.
SXXXX.XXXXXTT
“S” indicates a sign.
“TT” indicates the distance unit.
5-23 Section data
acquisition
SDR Requests the section loss and section return loss.
For the return value format, refer to page 8-60.
6-1 Drive setting FDAR Requests the drive name (m) and file name (n).
Return value format: m,n
m= 0: FD (expansion unit)
1: Built-in memory
2: -
3: PCMCIA
4: -
5: USB
n= File name
6-2 Folder setting DIRR Requests the folder name.
6-3 File type setting FFR Requests the file type.
m= 0: .TRB 6: .LST
1: - 7: .SOR(Telcordia)
2: .SET 8: .CSV
3: .SOR(Bellcore) 9: .TRD
4: .TIF 10: .TRA
5: .BMP 11: .4
6-4 Recorded capacity FSR m Requests the used capacity of the drive.
m: Specify the drive.
m= 0: FD (expansion unit)
1: Built-in memory
2: -
3: PCMCIA
4: -
5: USB
XXXXXXXXXXbyte
