YOKOGAWA AQ7260 OTDR

Chapter 8 USING OPTIONS AND EXTERNAL DEVICES
8-53
Device Message
No. Function
Header
Numeric
Part
Description
6-5 Recorded file name FAR m, n, o Request the names of recorded files.
Return value format:
XXXXXXX,XXXXXXX, xxx
m: Specify the drive.
m= 0: FD (expansion unit)
1: Built-in memory
2: -
3: PCMCIA
4: -
5: USB
n: Specify the folder.
o: Specify the file type.
o= 0: .TRB 6: .LST
1: - 7: .SOR(Telcordia)
2: .SET 8: .CSV
3: .SOR(Bellcore) 9: .TRD
4: .TIF 10: .TRA
5: .BMP 11: .4
6-6 Sub folder check SDIRR Requests the sub folders of the current folder.
Return value format: XXXXXXX,XXXXXXX,xxx
None will be returned if no sub folders exist.
6-7 Acquisition of file list
of current folder
CUDIR
Requires file list of folder selected FDA or DIR.
Each file names which separated by “,” are output.
Example
001.SOR,abc/
7-1 File recall No request command
7-2 File list print No request command
8-1 Data save No request command
8-2 Data overwriting No request command
9-1 File delete No request command
10-1 Drive initialize No request command
10-3 Folder make No request command
10-4 Folder delete No request command
10-5 Storage media state RERR Requests the storage media status.
0: Normal
1: -
2: No storage media is installed.
3: Not initialized
4: Writing inhibited
5: Selected not stored file
6: Selected stored file
7: Not enough media capacity
8: Other error
11-1 Trace type TRCR Requests the trace display method.
0: Dot
1: Line
11-2 Cursor type
Second cursor
CSRR Requests the cursor display method.
0: “+” (Second cursor OFF)
1: “|” (Second cursor OFF)
2: “+” (Second cursor ON)
3: “|” (Second cursor ON)
11-3 Grid show/hide
setting
GDR Requests to show/hide the grid.
0: Hides the grid.
1: Shows the grid.
