Chapter 2 CHANGING SYSTEM SETTINGS
2-19
Changing the Distance Reference Mark Type
The distance reference mark type can be changed as explained below.
♦ Example: “LINE” → “ARROW”
For the method of changing the distance reference, refer to page 7-27.
1. Locate the cursor to “DIST. REF. MARK” by using the rotary knob or the arrow
key.
2.
Press [ENTER].
A selection window will appear.
3. Locate the cursor to “ARROW” by using the rotary knob or [S] / [T].
4. Press [ENTER] to register the change made to the distance reference mark type.
The change will not be registered if [ESC] is pressed instead of [ENTER].
*LINE
Selectable
mark types
ARROW
*: Indicates the default setting.
Caution
Refer
TIP
