YOKOGAWA GS200 User Manual

Contents
Chapter 8 Synchronous Operation
8.1 Synchronous Operation Using the BNC I/O Terminals (IN and OUT) .............................. 8-1
8.2 Using the RJ-11 Connectors (SYNC IN and SYNC OUT) to Perform Synchronous
Operation ..........................................................................................................................
8-4
Chapter 9 Other Features
9.1 Initializing Setup Data ....................................................................................................... 9-1
9.2 Saving, Loading, and Deleting Setup Data ...................................................................... 9-2
9.3 Selecting the Settings
Applied at Power-On ..................................................................... 9-4
9.4 Selecting the Display Brightness,
Turning the Display Off, and Turning the Beep
Sound On and Off
............................................................................................................. 9-5
9.5 Selecting the CSV File Format ......................................................................................... 9-6
9.6 Error Log Display .......................................................................................................
....... 9-7
Chapter 10 USB Interface
10.1 USBInterfaceFeaturesandSpecications .................................................................... 10-1
10.2 Setting the USB Interface Mode ..................................................................................... 10-2
10.3 V
iewing the VISA Setup Information............................................................................... 10-3
Chapter 11 Ethernet Interface (Option)
11.1 EthernetInterfaceFeaturesandSpecications ..............................................................11-1
11.2 Connecting to a Network .................................................................................................11-2
11.3
ConguringNetworkSettings(TCP/IP) ...........................................................................11-3
11.4
Viewing the Network Settings ..........................................................................................11-6
11.5
Web Server Feature ........................................................................................................11-7
Chapter 12 GP-IB Interface
12.1 GP-IBInterfaceFeaturesandSpecications ................................................................. 12-1
12.2 Connecting the GP-IB Cable .......................................................................................... 12-2
12.3 Setting the GP-IB
Address and Command Mode ........................................................... 12-3
12.4 7651-Compatible Mode .................................................................................................. 12-4
12.5 Responses to Interface Messages ................................................................................. 12-5
12.6 About the IEEE 488.2-1992 Standard ............................................................................ 12-7
Chapter 13 Communication Commands
13.1 Program Format ............................................................................................................. 13-1
13.1.1 Symbols Used in the Syntax ............................................................................ 13-1
13.1.2 Messages ........................................................................................................ 13-1
13.1.3 Commands ...................................................................................................... 13-3
13.1.4 Responses ....................................................................................................... 13-5
13.1.5 Data
................................................................................................................. 13-5
13.2 Commands ......................................................................................................
............... 13-7
13.2.1 List of Commands ............................................................................................ 13-7
13.2.2 Output Commands (OUTPut group) .............................................................. 13-10
13.2.3 Source Commands (SOURce group) .............................................................13-1
1
13.2.4 Program Commands (PROGram group) ....................................................... 13-13
13.2.5 Measurement Commands (SENSe group) .................................................... 13-15
13.2.6 Measured V
alue Read Commands (INITiate, FETCh, READ, and MEASure
groups)
........................................................................................................... 13-17
13.2.7 Store/Recall Commands (TRACe group) ...................................................... 13-18
13.2.8 External I/O Commands (ROUT
e group) ....................................................... 13-20
13.2.9 System Commands (SYST
em group) ............................................................ 13-21
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
App
Index
xi
IM GS210-01EN
