Zebra DS4308 Product Reference Guide

Standard Default Parameters A - 3
Illumination Brightness 669 F1h 9Dh High
DS4308-XD only : Low
4-35
Low Light Scene Detection 810 F2h 2Ah Dim Illumination Low Light
Assist Scene Detection
4-36
Motion Tolerance (Hand-Held
Trigger Mode Only)
858 F2h 5Ah Less Motion Tolerance 4-37
Movement Sensitivity
(DS4308P Only)
1300 F8h 05h 14h Medium 4-38
Object Detection Method
(DS4308P Only)
857 F2h 59h IR Sensor Detection 4-39
Miscellaneous Options
Add an Enter Key N/A N/A N/A 4-40
Transmit Code ID Character 45 2Dh None 4-41
Prefix Value 99, 105 63h, 69h 7013 <CR><LF> 4-42
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
7013 <CR><LF> 4-42
Scan Data Transmission Format 235 EBh Data as is 4-43
FN1 Substitution Values 103, 109 67h, 6Dh 7013 <CR><LF> 4-44
Transmit “No Read” Message 94 5E Disable 4-45
Unsolicited Heartbeat Interval 1118 F8h 04h 5Eh Disable 4-46
Dump Scanner Parameters N/A N/A N/A 4-47
Imaging Preferences
Operational Modes N/A N/A N/A 5-4
Image Capture Illumination 361 F0h 69h Enable 5-5
Image Capture Autoexposure 360 F0h 68h Enable 5-5
Fixed Exposure 567 F4h F1h 37h 100 5-6
Fixed Gain 568 F1h 38h 50 5-6
Gain / Exposure Priority for
Snapshot Mode
562 F1h 32h Autodetect 5-7
Snapshot Mode Timeout 323 F0h 43h 0 (30 seconds) 5-8
Snapshot Aiming Pattern 300 F0h 2Ch Enable 5-9
Silence Operational Mode
Changes
1293 F8h 05h 0Dh Disable (Do Not Silence) 5-9
Image Cropping 301 F0h 2Dh Disable 5-10
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI
Number
Default
Page
Number

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
