Zebra DS4308 Product Reference Guide

A - 4 DS4308/DS4308P Digital Scanner Product Reference Guide
Crop to Pixel Addresses 315
316
317
318
F4h F0h 3Bh
F4h F0h 3Ch
F4h F0h 3Dh
F4h F0h 3Eh
0 top
0 left
799 bottom
1279 right
5-11
Image Size (Number of Pixels) 302 F0h 2Eh Full 5-12
Image Brightness (Target White) 390 F0h 86h 180 5-13
JPEG Image Options 299 F0h 2Bh Quality 5-13
JPEG Target File Size 561 F1h 31h 160 kB 5-14
JPEG Quality and Size Value 305 F0h 31h 65 5-14
Image Enhancement 564 F1h 34h Low (1) 5-15
Image File Format Selection 304 F0h 30h JPEG 5-16
Image Rotation 665 F1h 99h 0 5-17
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP 5-18
Signature Capture 93 5Dh Disable 5-19
Signature Capture Image File
Format Selection
313 F0h 39h JPEG 5-20
Signature Capture Bits per Pixel
(BPP)
314 F0h 3Ah 8 BPP 5-21
Signature Capture Width 366 F4h F0h 6Eh 400 5-22
Signature Capture Height 367 F4h F0h 6Fh 100 5-22
Signature Capture JPEG Quality 421 F0h A5h 65 5-22
Video Mode Format Selector 916 F2h 94h JPEG 5-23
Video View Finder 324 F0h 44h Disable 5-23
Target Video Frame Size 328 F0h 48h 2200 bytes 5-24
Video View Finder Image Size 329 F0h 49h 1700 bytes 5-24
USB Host Parameters
USB Device Type N/A N/A USB Keyboard HID 6-5
Symbol Native API (SNAPI)
Status Handshaking
N/A N/A Enable 6-7
USB Keystroke Delay N/A N/A No Delay 6-7
USB CAPS Lock Override N/A N/A Disable 6-8
USB Ignore Unknown
Characters
N/A N/A Enable 6-8
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI
Number
Default
Page
Number

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
