Product Overview and Features 1 - 13
Platter Stainless steel horizontal scanning surface; imaging
window for processing barcode data, and placing
items on the surface to determine weight.
5-6
Calibration Switch Used in manual scale calibration. n/a
CSS (Optional) Modular unit that fits into the MP70XX tower; used
for customer scanning.
3-11
Scale Display Single or dual display option provides the weight of
items on the scale.
5-5
Leveling Screws (medium and short models
only)
Standard length leveling screws ship with all short
and medium models.
Longer length screws are available as an accessory.
1-10
Connectors Connect the MP70XX to peripherals, and POS/host. Table 1-3
Internal USB Cap/Port The internal USB port is available under the platter. 1-10
EAS Cable Channel Cable routing channel for EAS antenna. 1-8
Scale Cable Channel Cable routing channel for the scale cable. 1-8
Drainage/Ventilation Holes Outlet for spills. 1-8
Table 1-3 Description of Connectors
Port Description
RS-232 AUX 2 (J7) See
Table 2-3 on page 2-13 for description.
0.0 (J6) Scale Display port.
RS-232 AUX 1 (J5) See
Table 2-3 on page 2-13 for description.
CKP I-LOCK (J4) Checkpoint EAS Interlock.
AUX A-B (J3) Dual USB 2.0 full speed ports for auxiliary USB scanners, CSS, or mass
storage device.
NOTE An additional USB port is available in the front under the platter. All USB ports
can be used for the USB staging flash drive. See
Table 2-14 on page 2-56 and
USB Staging Flash Drive on page 5-10 for more information.
POS (J2) Point of Sale terminal port.
12V DC (J1) External power input. 12V / 3.33A (not required if powered from terminal).
NOTE If a power supply plug is inserted to the J1 connector, with no voltage to the
power supply, the scanner will not power up.
Table 1-2 Features on the MP7000 Scanner Scale (Continued)
Feature Description Page
