Chapter 20 Interface Setup
GS1920v2 Series User’s Guide
117
CHAPTER 20
Interface Setup
20.1 Interface Setup Overview
This chapter shows you how to create virtual interfaces for interface-based configurations. An IPv6
address is configured on a per-interface basis. The interface can be a physical interface (for example,
an Ethernet port) or a virtual interface (for example, a VLAN).
20.2 Interface Setup
Use this screen to view and set IPv6 interfaces on which you can configure an IPv6 address to access
and manage the Switch.
The interfaces you create here will only take effect after you configure them in the SYSTEM > IPv6
screens.
Click SYSTEM > Interface Setup in the navigation panel to display the configuration screen.
Figure 73 SYSTEM > Interface Setup
The following table describes the labels in this screen.
Table 29 SYSTEM > Interface Setup
LABEL DESCRIPTION
Index This field displays the index number of an entry.
Interface Type This field displays the type of interface.
Interface ID This field displays the identification number of the interface.
Interface This field displays the interface’s descriptive name which is generated automatically by the
Switch. The name is from a combination of the interface type and ID number.
Select an entry’s check box to select a specific entry. Otherwise, select the check box in the
table heading row to select all entries.
Add/Edit Click Add/Edit to add a new interface or edit a selected one.
Delete Click Delete to remove the selected interfaces.
