Chapter 21 IP Setup
GS1920v2 Series User’s Guide
122
21.3 IP Setup
Use this screen to configure the default gateway device, the default domain name server and add IP
domains. Click SYSTEM > IP Setup > IP Setup in the navigation panel to display the screen as shown.
Note: The Switch allows you to set a static IP interface in the same subnet that already has a
DHCP-assigned IP interface on the Switch. The Switch will use the static IP you set and
the DHCP-assigned IP will be set to 0.0.0.0.
Figure 78 SYSTEM > IP Setup > IP Setup
Renew Time This displays the length of time from the lease start that the Switch will request to renew its
current dynamic IP address from the DHCP server.
Rebind Time This displays the length of time from the lease start that the Switch will request to get any
dynamic IP address from the DHCP server.
Lease Time Start This displays the date and time that the current dynamic IP address assignment from the DHCP
server began. You should configure date and time in SYSTEM > General Setup.
Lease Time End This displays the date and time that the current dynamic IP address assignment from the DHCP
server will end. You should configure date and time in SYSTEM > General Setup.
Default
Gateway
This displays the IP address of the default gateway assigned by the DHCP server. 0.0.0.0 means
no gateway is assigned.
Primary /
Secondary DNS
Server
This displays the IP address of the primary and secondary DNS servers assigned by the DHCP
server. 0.0.0.0 means no DNS server is assigned.
Table 33 SYSTEM > IP Setup > IP Status > IP Status Details: DHCP (continued)
LABEL DESCRIPTION
