Chapter 39 Multicast
GS1920v2 Series User’s Guide
231
39.6 IPv6 Multicast
Click SWITCHING > Multicast > IPv6 Multicast > IPv6 Multicast Status to display the screen as shown. This
screen shows the IPv6 multicast group information. See Section 39.1 on page 219 for more information
on multicasting.
Figure 159 SWITCHING > Multicast > IPv6 Multicast > IPv6 Multicast Status
The following table describes the fields in the above screen.
39.7 MLD Snooping-proxy
Click SWITCHING > Multicast > IPv6 Multicast > MLD Snooping-proxy to display the screen as shown. See
Section 39.1 on page 219 for more information on multicasting.
Figure 160 SWITCHING > Multicast > IPv6 Multicast > MLD Snooping-proxy
Table 111 SWITCHING > Multicast > IPv6 Multicast > IPv6 Multicast Status
LABEL DESCRIPTION
Index This is the index number of the entry.
VID This field displays the multicast VLAN ID.
Port This field displays the port number that belongs to the multicast group.
Multicast Group This field displays IP multicast group addresses.
Group Timeout This field displays the time (in seconds) that elapses before the Switch removes a MLD group
membership entry if it does not receive report messages from the port.
