3.3 LEDs
After you connect the power to the Switch, view the LEDs to ensure proper functioning of the Switch
and as an aid in troubleshooting.
Table 7 LED Descriptions
LED COLOR STATUS DESCRIPTION
PWR Green On The Switch is receiving power from the power module in the
power slot.
Blinking The Switch is returning to the last-saved custom default
configuration settings.
Amber On The Switch is returning to its factory default configuration
settings.
Off The Switch is not receiving power from the power module in
the power slot.
SYS Green On The Switch is on and functioning properly.
Blinking The Switch is rebooting and performing self-diagnostic tests.
Red On The Switch is functioning abnormally.
Off The power is off or the Switch is not ready or malfunctioning.
CLOUD Green On The Switch has successfully connected to the NCC (Nebula
Control Center).
Blinking The Switch cannot connect to the NCC because it is not
registered.
Amber On The Switch is registered at NCC but cannot connect to the
NCC. Please check the Internet connection of the Switch.
Blinking The Switch is not registered at NCC and cannot connect to the
NCC. Please check the Internet connection of the Switch and
register the Switch at NCC.
Off The Switch is operating in standalone mode. Nebula Control
Center Discovery is disabled in SYSTEM > Cloud Management >
Nebula Control Center Discovery in the Switch Web
Configurator.
LOCATOR Blue On The Switch is uploading firmware. While the Switch is doing this,
do not turn off the power.
Blinking Shows the actual location of the Switch between several
devices in a rack. The default timer is 30 minutes when you are
configuring the Switch.
Off The locator is not functioning or malfunctioning.
