Chapter 11 MAC Table
GS1920v2 Series User’s Guide
93
The following table describes the labels in this screen.
Table 17 MONITOR > MAC Table
LABEL DESCRIPTION
Condition Select one of the below search conditions and click Search to only display the data which
matches the criteria you specified.
Select All to display any entry in the MAC table of the Switch.
Select Static to display the MAC entries manually configured on the Switch.
Select MAC and enter a MAC address in the field provided to display a specified MAC entry.
Select VID and enter a VLAN ID in the field provided to display the MAC entries belonging to the
specified VLAN.
Select Port and enter a port number in the field provided to display the MAC addresses which
are forwarded on the specified port.
Select Trunk and type the ID of a trunk group to display all MAC addresses learned from the ports
in the trunk group.
Sort by Define how the Switch displays and arranges the data in the summary table below.
Select MAC to display and arrange the data according to MAC address.
Select VID to display and arrange the data according to VLAN group.
Select PORT to display and arrange the data according to port number.
Type Transfer Select Dynamic to MAC forwarding and click the Transfer button to change all dynamically
learned MAC address entries in the summary table below into static entries. They also display in
the SWITCHING > Static MAC Forwarding screen.
Select Dynamic to MAC filtering and click the Transfer button to change all dynamically learned
MAC address entries in the summary table below into MAC filtering entries. These entries will then
display only in the SWITCHING > Static MAC Filtering screen and the default filtering action is
Discard source.
Search Click this to search data in the MAC table according to your input criteria.
Transfer Click this to perform the MAC address transferring you selected in the Type Transfer field.
Cancel Click Cancel to change the fields back to their last saved values.
Index This is the incoming frame index number.
MAC Address This is the MAC address of the device from which this incoming frame came.
VID This is the VLAN group to which this frame belongs.
Port This is the port where the above MAC address is forwarded.
Type This shows whether the MAC address is Dynamic (learned by the Switch) or Static (manually
entered in the SWITCHING > Static MAC Forwarding screen).
