Parameters 189
02.03 DIO STATUS
Status word of digital inputs/outputs DIO1…3.
Example: 001 = DIO1 is On, DIO2 and DIO3 are Off.
- / Pb
0b000...0b111 Digital input output status word 1 = 1 / -
02.04 AI1
Shows the value of analog input AI1.
The type is selected with jumper J1 on the JCU
control unit.
- / Real
-11.000...
11.000 V
Analog input AI1 value in V or mA. 1000 = 1 V
/mA / -
02.05 AI1 SCALED
Shows the scaled value of analog input AI1.
See parameters 13.04 AI1 MAX SCALE and 13.05
AI1 MIN SCALE.
- / Real
-32768.000...
32768.000
Analog input AI1 scaled value. - / 1000 = 1
02.06 AI2
Shows the analog input AI2 value.
The type is selected with jumper J2 on the JCU
control unit.
- / Real
-11.000...
11.000 V
Analog input AI2 value in V or mA. 1000 = 1 V
/mA / -
02.07 AI2 SCALED
Shows the scaled value of analog input AI2.
See parameters 13.09 AI2 MAX SCALE and
13.10 AI2 MIN SCALE.
- / Real
-32768.000...
32768.000
Analog input AI2 scaled value. - / 1000 = 1
02.08 AO1
Shows the value of analog output AO1. - / Real
0.000...
22.700 mA
Analog output AO1 value in mA. 1000 =
1mA / -
02.09 AO2
Shows the value of analog output AO2. - / Real
-10.000...
10.000 V
Analog output AO2 value in V. 1000 =
1 V / -
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Name Value Information
0 DIO1 1 Digital input/output DIO1 is On.
0 Digital input/output DIO1 is Off.
1 DIO2 1 Digital input/output DIO2 is On.
0 Digital input/output DIO2 is Off.
2 DIO3 1 Digital input/output DIO3 is On.
0 Digital input/output DIO3 is Off.
3 NOT USED
