ABB ACL30 User Manual

Parameters 223
13.04 AI1 MAX SCALE
Defines the real value that corresponds to the
maximum analogue input value defined by
parameter 13.02 AI1 MAX.
1500.000/
Real
-32768.000
…32768.000
Real value corresponding to the value of parameter
13.02.
- / 1000 = 1
13.05 AI1 MIN SCALE
Defines the real value that corresponds to the
minimum analogue input value defined by parameter
13.03 AI1 MIN. See parameter 13.04 AI1 MAX
SCALE.
-1500.000/
Real
-32768.000
…32768.000
Real value corresponding to the value of parameter
13.03.
- / 1000 = 1
13.06 AI2 FILT TIME
Defines the filter time constant for analogue input
AI2. See parameter 13.01 AI1 FILT TIME.
0.000 s/
Real
0.000…30.000 s Filter time constant for AI2. 1000 = 1 s / -
13.07 AI2 MAX
Defines the maximum value for analogue input AI2.
The type is selected with jumper J2 on the JCU
Control Unit.
10.000/ V
Real
-11.000…
11.000 V /
-22.000…
22.000 mA
Maximum AI2 input value. 1000 = 1 V
or mA / -
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
AI (scaled)
AI (mA / V)
13.02
13.03
13.05
13.04
