ABB ACL30 User Manual

Parameters 247
46.08 MOT TEMP
SOURCE
Selects the motor temperature protection. When
overtemperature is detected, the drive reacts as
defined by parameter 46.07 MOT TEMP PROT.
*Note: If one FEN-xx module is used, parameter
setting must be either KTY 1st FEN or PTC 1st FEN.
The FEN-xx module can be in either Slot 1 or Slot 2.
Estimated /
enum
Estimated
The temperature is supervised based on the motor
thermal protection model and the ambient
temperature.
WARNING! The model does not protect
the motor if it does not cool properly due to
dust and dirt.
KTY JCU The temperature is supervised using a KTY84
sensor connected to drive thermistor input TH.
1
KTY 1st FEN The temperature is supervised using a KTY84
sensor connected to encoder interface module FEN-
xx installed in drive Slot 1/2. If two encoder interface
modules are used, encoder module connected to
Slot 1 is used for the temperature supervision.
Note: This selection does not apply to FEN-01. *
2
KTY 2nd FEN The temperature is supervised using a KTY84
sensor connected to encoder interface module FEN-
xx installed in drive Slot 1/2. If two encoder interface
modules are used, encoder module connected to
Slot 2 is used for the temperature supervision.
Note: This selection does not apply to FEN-01. *
3
PTC JCU The temperature is supervised using 1…3 PTC
sensors connected to drive thermistor input TH.
4
PTC 1st FEN The temperature is supervised using a PTC sensor
connected to encoder interface module FEN-xx
installed in drive Slot 1/2. If two encoder interface
modules are used, encoder module connected to
Slot 1 is used for the temperature supervision. *
5
PTC 2nd FEN The temperature is supervised using a PTC sensor
connected to encoder interface module FEN-xx
installed in drive Slot 1/2. If two encoder interface
modules are used, encoder module connected to
Slot 2 is used for the temperature supervision. *
6
46.09 MOT TEMP ALM
LIM
Defines the alarm limit for motor overtemperature
protection (when parameter 46.07 MOT TEMP
PROT = Alarm / Fault).
90 °C/ INT32
0…10000 °C Motor overtemperature alarm limit. 1 = 1 °C / -
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
