Parameters 249
46.84 AUTORESET SEL
Selects the faults that are automatically reset. The
parameter is a 16-bit word with each bit
corresponding to a fault type. Whenever a bit is set to
1, the corresponding fault is automatically reset.
The bits of the binary number correspond to the
following faults monitored by 05.02 LIFT FW.
0x4000 / Pb
0x0000…0xFFFF The faults that are automatically reset.
- / 1 = 1
47
47 VOLTAGE CTRL
Settings for undervoltage control, supply voltage and
the low voltage mode.
47.01 LOW VOLT MOD
ENA
Selects a signal source that enables/disables the low
voltage mode. 0 = Low voltage mode disabled, 1 =
Low voltage mode enabled. See section Rescue
operation on page 173.
C.False/
Bit pointer
Bit pointer: CONST or POINTER (See Terms and
abbreviations on page 183.)
- / 1 = 1
47.02 LOW VOLT DC MIN
Minimum DC voltage for the low voltage mode. See
section Rescue operation on page 173.
250.0 V /
Real
250.0…450.0 V Minimum DC voltage for the low voltage mode. 1 = 1 V / -
47.03 LOW VOLT DC MAX
Maximum DC voltage for the low voltage mode. See
section Rescue operation on page 173.
Note: The value of this parameter must be higher
than (47.02 LOW VOLT DC MIN + 50 V).
250.0 V /
Real
350.0…810.0 V Maximum DC voltage for the low voltage mode. 1 = 1 V / -
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Fault
0 SPEED MATCH
1 TORQUE PROVE
2 BRAKE SLIP
3 MOTOR STALL
4…7 NOT USED
8 SHORT CIRCUIT
9 OVERCURRENT
10 OVERVOLTAGE
11 UNDERVOLTAGE
12 EXTERNAL FAULT
13 MOTOR PHASE LOSS
14 ALL FAULTS
15 NOT USED
