ABB ACL30 User Manual

Parameters 281
97.04 LM USER
Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000 p.u.
/ Real24
0.00000…
10.00000 p.u
Main inductance. - / 100000 =
1 p.u
97.05 SIGMAL USER
Defines the leakage inductance σL
S
.
Note: This parameter is valid only for asynchronous
motors.
0.00000 p.u.
/ Real24
0.00000…
1.00000 p.u
Leakage inductance. - / 100000 =
1 p.u
97.06 LD USER
Defines the direct axis (synchronous) inductance.
Note: This parameter is valid only for permanent
magnet motors.
0.00000 p.u.
/ Real24
0.00000…10.000
00 p.u
Direct axis (synchronous) inductance. - / 100000 =
1 p.u
97.07 LQ USER
Defines the quadrature axis (synchronous)
inductance.
Note: This parameter is valid only for permanent
magnet motors.
0.00000 p.u.
/ Real24
0.00000…10.000
00 p.u
Quadrature axis (synchronous) inductance. - / 100000 =
1 p.u
97.08 PM FLUX USER
Defines the permanent magnet flux.
Note: This parameter is valid only for permanent
magnet motors.
0.00000 p.u.
/ Real24
0.00000…2.0000
0 p.u
Permanent magnet flux. - / 100000 =
1 p.u
97.09 RS USER SI
Defines the stator resistance R
S
of the motor model. 0.00000
Ohm /
Real24
0.00000…
100.00000 Ohm
Stator resistance. - / 100000 =
1 Ohm
97.10 RR USER SI
Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000
Ohm /
Real24
0.00000…
100.00000 Ohm
Rotor resistance. - / 100000 =
1 Ohm
97.11 LM USER SI
Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00 mH /
Real24
0.00 …
100000.00 mH
Main inductance. - / 100 = 1
mH
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
