ABB ACL30 User Manual

282 Parameters
97.12 SIGL USER SI
Defines the leakage inductance σL
S
.
Note: This parameter is valid only for asynchronous
motors.
0.00 mH /
Real24
0.00…
100000.00 mH
Leakage inductance. - /
100 = 1 mH
97.13 LD USER SI
Defines the direct axis (synchronous) inductance.
Note: This parameter is valid only for permanent
magnet motors.
0.00 mH /
Real24
0.00…
100000.00 mH
Direct axis (synchronous) inductance. - /
100 = 1 mH
97.14 LQ USER SI
Defines the quadrature axis (synchronous)
inductance.
Note: This parameter is valid only for permanent
magnet motors.
0.00 mH /
Real24
0.00
…100000.00 mH
Quadrature axis (synchronous) inductance. - /
100 = 1 mH
97.15 NOMINAL TORQUE
Nominal torque in N•m which corresponds to 100%.
Note: This parameter is copied from parameter
99.12 MOT NOM TORQUE, if given. Otherwise the
value is calculated.
0.000
N•m /
INT32
0.000…
2147483.647 N•m
Nominal torque.
- /
1000 = 1 N•m
97.16 POLEPAIRS
Calculated number of motor pole pairs.
Note: This parameter cannot be set by the user.
0 / UINT32
0…1000
Calculated number of motor pole pairs.
1 = 1 / -
97.17 POS OFFSET
USER
Defines an angle offset between the zero position of
the synchronous motor and the zero position of the
position sensor.
Notes:
• The value is in electrical degrees. The electrical
angle equals the mechanical angle multiplied by
the number of motor pole pairs.
• This parameter is valid only for permanent magnet
motors.
0 deg / Real
0…360 deg Angle offset. - / 1 = 1 deg
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
