80 Start-up and control
Adjusting parameter values
In the Main menu, highlight PARAMETERS and
press .
• Use the and keys to browse the
list of parameter groups. Highlight the desired
group and press to display the parameters
within that group.
• Highlight a parameter and press to adjust
the value.
• Use and to adjust the value. (When
adjusting pointer parameters, use the NEXT key to
move between parameter group, index and bit
settings.)
• Press to accept the new parameter value,
to retain the old value.
• At any point, press or to return to the
previous level.
Notes:
For more detailed instructions on adjusting parameter values, see the following sections:
• Selecting a parameter and changing its value on page 97
• Changing the value of value pointer parameters on page 99
• Pointing the bit pointer parameter to a bit value in another signal on page 101
• Changing bit pointer parameter value to 0 or 1 on page 103.
Changing the language
By default, the language of the text shown is English.
If desired, the language can be changed.
99.01 LANGUAGE
Entering motor data
Select the motor type: asynchronous or permanent
magnet motor.
99.02 MOTOR TYPE
Enter the motor data from the motor nameplate.
Note: Set the motor data to exactly the same value
as on the motor nameplate. For example, if the motor
nominal speed is 1470 rpm on the nameplate, setting
the value of parameter 99.06 MOT NOM SPEED to
1500 rpm results in wrong operation of the drive.
At least parameters 99.02…99.07 must be set. Better
control accuracy can be achieved by setting also
parameters 99.08…99.09.
• Motor nominal current
Allowed range: approximately 1/6
· I
2n
… 2 · I
2n
of
the drive.
99.03 MOT NOM CURRENT
ENTER
SEL
EDIT
SAVE
CANCEL
CANCEL
EXIT
