Indicator
Issue
Resolution
Reset
Source
Hardware Error
Rollup of hardware
diagnostics at the DTC
Check the DTC and DTC Zone
Indicators.
AOC
OVEN.DTC1
Software Error
Rollup of software faults
at the DTC
Check the DTC and DTC Zone
Indicators.
AOC
OVEN.DTC1
T-Rating Conflict
DTC T-Rating does not
match As-Built T-Rating
Possible Configuration Error, contact
ABB for more information.
AOC
OVEN.DTC1
High Temperature
Temperature out of range
(high)
Check setting at Setup
Tab>Oven>DTC# Button. Adjust as
needed.
AOC
DTC Zone
Low Temperature
Temperature out of range
(low)
Check setting at Setup Tab
>Oven>DTC# Button. Adjust as
needed.
AOC
DTC Zone
Out of Control
Temperature deviates >
±10° from setpoint
Check analysis temperature control TCF
settings. Check Zone indicators and
Diagnostic Displays.
AOC
DTC Zone
Over temp
Temperature exceeds
Max limit for T-Rating
Defective temperature sensor. Contact
ABB for more information.
AOC
DTC Zone
Ramp Out of
Control (Future
Use)
Temperature deviates >
±10° from setpoint
during Temperature
Ramp
Check analysis temperature control TCF
settings. Check Zone indicators and
Diagnostic Displays.
AOC
DTC Zone
Temperature
Sensor Fault
Temperature
Measurement out of
valid range
From the Setup Tab, check the
temperature settings. Replace
temperature sensor if needed.
AOC
DTC Zone
DTC Digital Input 1
Low oven purge air
pressure. Open on alarm
Check purge pressure setting at ovens
front panel gauge. Adjust as necessary.
Check instrument air supply pressure.
Check oven purge pressure switch.
AOC
Ovn#DTC#.
1
DTC Digital Input
2-14
Optional Hardware
inputs; Open on alarm
Verify option input device is functioning
properly.
AOC
Ovn#DTC#.
2-14
Common Alarm
Relay Override
DigIn 16
Open input overrides the
common alarm output
Verify proper operation of common
alarm override switch.
AOC
Ovn#.DTC#.
D1
Hardware Error
Rollup of hardware
diagnostics at the EPC
Check the EPC and EPC Group Zone
indicators.
AOC
Ovn#.EPC
Software Error
Rollup of software faults
at the EPC
Check the EPC and EPC Group Zone
indicators.
AOC
Ovn#.EPC
EPC Zone One
(1- 10)
Rollup of Zone (1-10)
Indicators
Check EPC Zone specific indicators and
correct as necessary.
AOC
EPC Zones
Pressure Sensor
Fault
Defective pressure
sensor
Replace Pressure sensor if needed.
AOC
Ovn#.EPC.P
Z.#
Low Alarm
Pressure out of range
(low)
Adjust pressure zone's low limit under
the Setup Tab. Verify supply pressure
to the zone. Correct as necessary.
Replace EPC sensor or solenoid valve as
necessary.
AOC
Ovn#.EPC.P
Z.#
High Alarm
Pressure out of range
(high)
Adjust pressure zone's high limit under
the Setup Tab. Replace EPC sensor or
solenoid valve as necessary.
AOC
Ovn#.EPC.P
Z.#
Ramp Out of
Control
Pressure deviates > ±x
psi from setpoint during
Pressure Ramp
Check analysis pressure control TCF
settings. Check Zone indicators and
Diagnostic Displays.
AOC
Ovn#.EPC.P
Z.#
Out of Control
Pressure deviates > ±x
psi from setpoint
Check analysis pressure control TCF
settings. Check Zone indicators and
Diagnostic Displays.
AOC
Ovn#.EPC.P
Z.#
Software Error
Rollup of software faults
at the Det Amp
Check indicators and Diagnostic
Displays at Detector Amplifier.
AOC
Ovn#.DTM#
Hardware Error
Rollup of hardware
diagnostics at the Det
Amp
Check indicators and Diagnostic
Displays at Detector Amplifier.
AOC
Ovn#.DTM#
