Managing geometry results
Since there are generally more solutions possible than desired,
all possible solutions are presented (without a step number). To
keep the result required, use the Up Arrow or Down Arrow keys
to move the cursor to that feature and press the Keep One Result
soft key.
When the cursor is on an existing feature the following soft keys
are available:
Soft key Function
Pressing the Keep All Results soft key will
save all results found
Pressing the Clear Results soft key will clear
all results not saved
When the cursor is on a feature that is not saved, the following soft
keys are available:
Soft key Function
Pressing the Keep One Result soft key will
save the highlighted result found
Pressing the Clear Results soft key will clear
all results not saved
After selecting the features to be retained, press the Clear Results
soft key to remove the remaining unselected results from the
listing.
Existing or new features can be viewed (or edited) by moving the
cursor to the step and pressing the ENTER key.
The results are cleared automatically when the Find Function soft
key is pressed again.
Returning features to the part program
Press the Return Feature soft key to transfer the current geo
step to the part program.
The soft key is disabled when it is not possible to transfer the
current step to the program.
If no program step is open, Return Feature adds an equivalent
program step at the current location. The system returns to PGM
view with the new step open.
If a program step is open, Return Feature (GeoPoint) returns
the GeoPoint’s coordinate to the current field (x and z)
If a program step is open, Return Feature (GeoLine or GeoArc)
is only possible if the feature matches the step type
If the return type does not match the destination step/field,
nothing is returned
Geometry calculator functions
Pressing the Calc Functions soft key opens a pop-up menu for
selecting a function
