ACU-RITE TURNPWR - Recess Cycles; Recess

Program steps and cycles | Recess cycles
8.6 Recess cycles
Recessing steps are used to machine simple or irregular recesses
into the part using a recess tool.
Recess
A Recess is used to remove material from within the middle of
either surface of the part using a recessing tool.
From the PGM screen, press the RECESS key to access the
Recess popup menu
Select Recess from the popup menu
8
ACU-RITE | TURNPWR | User's Manual | 08/2020
129
