6.6 Tool data
Field Description
Tool
Number of the tool
Type
The tool type (rough, finish, recess, button,
thread, drill, tap, bore)
Orientation
The tool orientation, refer to the help image
for the orientation number
Radius
The cutting edge radius (rough, finish,
recess, or button tools). Hole diameter
(divided by 2) for drill tools.
Length
Length of the tool (drill, tap, recess)
Width
Width of the tool (recess)
X Offset
Offset from the tool to the X workpiece
surface
Z Offset
Offset from the tool to the Z workpiece
surface
Tool Angle
Angle from the surface of the part to the
primary cutting edge of the tool (rough,
finish)
Point Angle
Angle from the primary cutting edge to the
secondary edge (rough, finish)
