Setup | Overview
11
11.1 Overview
The control has a set of parameters that can be setup as default
values. Some of these values can be overridden per the program
step dialogue, while others remain in effect until changed in the
Job Setup dialogue.
Job setup
Job Setup parameters can be changed to accommodate specific
machining requirements for each job.
To access the Job Setup dialogue:
Press the SETUP key
The Job Setup dialogue is displayed
Installation setup
Once in the Job Setup dialogue the Installation Setup dialogue can
be accessed.
To access the Installation Setup dialogue:
Press the Install Setup soft key
The Install Setup dialogue is displayed
Installation setup parameters are established during the initial
installation and typically are not changed. The installation setup
parameters are protected by a passcode. These parameters are
described within the control's Installation Manual.
Tool table
A brief overview of the tool table is provided later in this chapter. In
the table, up to 100 tools can be entered and used in any program
that would required that tool. For additional information, see "Tool
table", Page 85.
To access the tool table:
Press the Tool Table soft key
The Tool Table is displayed
Message log
The message log records all errors, and retains up to the last 128
messages in the control until it is deleted. A message in the log
can be highlighted, and an explanation of the message can be
displayed by pressing the Info soft key.
The message log entries may also be cleared from the
DRO or PGM screen by pressing the 0 key.
To access the message log:
Press the Message Log soft key
The Message Log is displayed
174
ACU-RITE | TURNPWR | User's Manual | 08/2020
