DRO mode | Status bar display
4
4.3 Status bar display
Status bar
display
Description
Program
state
This field indicates the program state:Stop when
program is not running, Run when program is
running, or Pause when program is paused for
operator.
Feed This field indicates the current feedrate of the axes.
Tool
In DRO mode, this field indicates the current tool
selection. In PGM mode, this field indicates the
programmed tool for the highlighted step ( TPT
programs only).
Datum This field indicates the active datum number.
Rad/Dia This area shows the "Ø" symbol when X-Axis is in
Diameter mode, or nothing when in Radius mode.
Units This field indicates the active display units. All
dimensions are displayed in these units (inch or
mm). The current feedrate is displayed in these
units (inch or mm per minute).
Estimated
time
This field indicates the estimated machining time
for the active program. This time assumes the
program runs at 100% of the programmed feeds.
It does not include the time necessary to perform
manual operations such as changing a tool. An
unfinished simulation run will result in no time
displayed (--:--:--).
Part clock This field shows the cumulative running time of
the current program. The timer is reset when a
program is loaded.
Parts This field shows the number of times the current
program was run to create a part.
Job clock This field shows the total elapsed time for the
current job. For additional information, see "Job
clock", Page 177.
Time of
day
This field shows the current time.
50
ACU-RITE | TURNPWR | User's Manual | 08/2020
