Setup | Job setup
11
Feed rate
The parameters set here will be used as the default by the control
and will only change if it is modified in any of the turning functions
dialogue.
Highlight the Default field, and specify the inch per minute
Select the unit of measure, Inch or MM by pressing the
appropriate soft key
Highlight the Dry Run field
Enter the inches per minute that is required. The default is 80
IPM.
Highlight the Full Cut override field
Enter the override percentage to be applied to the feed rate
when making full cuts
Highlight the Max override field
Enter the maximum percent override at full potentiometer
Display
Highlight the Stepover field, and either select Percentage to
use a factor of the tool's radius, or select Distance to use an
exact distance
Highlight the Angles field and select Degrees, or DMS.
Highlight the Res. Inch and Res. MM fields to select the desired
display resolution for the DRO display
Highlight the Help Imgs field and set to eitherOn to always
show the field graphic assistant in a step form or set to
Automatic for displaying additional fields when available in place
of the graphic assistant
Parts counter
The parts counter appears on the status bar when in DRO mode
or running a program. Use this feature to track how many times
the current program has run and how many parts have been
completed.
Here, setting the parts counter and stopping or starting the Job
Clock are setup. Using setup, the number of parts for the parts
counter can be set or reset.
Preset a starting count by entering the value in the Parts field
The parts counter resets to 0 when a new program is
loaded.
176
ACU-RITE | TURNPWR | User's Manual | 08/2020
