106 1100 Series Nano Pump Service Manual
3 Repairing the Pump
Cleaning the Nano Pump
The nano pump case should be kept clean. Cleaning should be done with a soft
cloth slightly dampened with water or a solution of water and a mild
detergent. Do not use an excessively damp cloth as liquid can drop into the
nano pump.
Using the ESD Strap
Electronic boards are sensitive to electrostatic discharge (ESD). In order to
prevent damage, always use an ESD strap supplied in the standard accessory
kit (see “Nano Pump Accessory Kit G2226-68705” on page 172) when handling
electronic boards and components.
Using the ESD Strap
1 Unwrap the first two folds of the band and wrap the exposed adhesive side
firmly around your wrist.
2 Unroll the rest of the band and peel the liner from the copper foil at the
opposite end.
3 Attach the copper foil to a convenient and exposed electrical ground.
Do not let liquid drip into the nano pump. It could cause shock hazard and it could
damage the nano pump.
Figure 12 Using the ESD Strap
