1100 Series Nano Pump Service Manual 217
Introduction to the Nano Pump 5
LAN Board
The HP JetDirect cards are network interface cards used in HP printers.
The following cards can be used with the Agilent 1100 modules.
Recommended Cables
For point to point connection (not using a network hub) use a twisted pair
cross over LAN cable (P/N 5183-4649, 10 feet long).
For standard network connections using a hub use category 5 UTP cables,
(P/N G1530-61480, 8 m long).
One board is required per Agilent 1100 stack. It is recommended to add the LAN board to
the detector with highest data rate.
The LAN board can only be used together with:
a main board version G13XX-66520 (DAD/MWD/VWD/Pump/ALS) or
G13XX-66500 (FLD/RID) and above.
an Agilent-ChemStation software revision A.06.01 or above.
Table 49 LAN Boards
Agilent Order Number Supported networks
J4106A Ethernet/802.3, RJ-45 (10Base-T(
J4105A Token Ring/802.5, DB9, RJ-45 (10Base-T)
J4100A Fast Ethernet, Ethernet/802.3, RJ-45 (10/100Base-TX) + BNC
(10Base2)
Minimum firmware of the JetDirect cards is A.05.05.
