232 1100 Series Nano Pump Service Manual
6 Control Module Screens for the Nano Pump
Major keys on the Agilent 1100 Control Module
ESC Return to previous screen, abort any change of parameters and toggle between
the last two top layer views
m Open context sensitive menus
i Information/Help
Enter Store changed parameters or execute a choice
Done (If available) Activate settings of current screen
On/Off Switch on individual Instrument(s) or complete System
Start Start a location range or sequence
Plot View online signals
Views Change between analysis - (samples)- status - system views
The screens shown on the next pages are based on the following firmware revisions:
Control Module firmware revision B.02.0x (G1323B).
HPLC Module firmware revision 5.0x.
In case the control module’s display seems to be frozen (hang-up due to a communication
problem on the CAN bus) unplug the control module from the HPLC module and reconnect.
