2 1100 Series Nano Pump Service Manual
1 Installing the Pump
Site Requirements
A suitable environment is important to ensure optimum performance of the
nano pump.
Power Consideration
The nano pump power supply has wide ranging capability (see Table 1 on page
3). It accepts any line voltage in the range described in the above mentioned
table. Consequently there is no voltage selector in the rear of the nano pump.
There are also no externally accessible fuses, because automatic electronic
fuses are implemented in the power supply.
Power Cords
Different power cords are offered as options with the nano pump. The female
end of each of the power cords is identical. It plugs into the power-input socket
at the rear of the nano pump. The male end of each of the power cords is
different and designed to match the wall socket of a particular country or
region.
To disconnect the nano pump from line, unplug the power cord. The power supply
still uses some power, even if the power switch on the front panel is turned off.
Shock hazard or damage of your instrumentation can result, if the devices are
connected to a line voltage higher than specified.
Never operate your instrumentation from a power outlet that has no ground
connection. Never use a power cord other than the power cord designed for your
region.
