Agilent Technologies 1100 Series Service Manual

1100 Series Nano Pump Service Manual 169
Parts and Materials 4
Cover Parts
Table 23 Cover Parts
Item Description Part Number
1 Plastic cover kit (includes top, base and both sides) G1312-68703
2 Front plate G1376-60011
3 Logo plate, Agilent 1100 5042-1381
Figure 33 Cover Parts
3
1
2
