214 1100 Series Nano Pump Service Manual
5 Introduction to the Nano Pump
Firmware Updates
Firmware updates can be done using your user interface:
• handheld control module with files from a PC-card or
• Agilent ChemStation with files from floppy disk
The file naming conventions are:
xxxx-vvv.DLB, where
xxxx is the product number, e.g. 2226 for the G2226A Nano Pump), and
vvv is the revision number, for example 503 is revision 5.03.
For instructions refer to your user interface.
Update of main system can be done in the resident system only.
Update of the resident system can be done in the main system only.
Figure 44 Firmware Update Mechanism
Resident System Main System
resident FW update
main FW update
