1100 Series Nano Pump Service Manual 161
Parts and Materials 4
Nano Pump Hydraulic Path
Table 17 Nano pump hydraulic path
Item Description Part Number
1 EMPV to FS cap (220 mm, 25 µm) for nanoflow sensor G1375-87321
2 Outlet ball valve to piston 2 capillary G1312-67300
3 FS to inj valve cap (350 mm, 25 µm) for nanoflow sensor
FS to inj valve cap (550 mm, 25 µm) for nanoflow sensor
G1375-87322
G1375-87323
4 Mixing capillary G1312-67302
5 Connection tube G1311-67304
6 Restriction capillary G1312-67304
7 Filter assembly (includes frit)
Frit
5064-8273
5022-2185
8 Filter to EMPV cap (280 mm, 170 µm) G1375-87400
9 Damper to filter capillary (130 mm, 250µm) 01090-87308
10 Solvent tube (pack of 4) G1322-67300
Corrugated waste tube, 120 cm (re-order 5 m) 5062-2463
