1100 Series Nano Pump Service Manual 3
Installing the Pump 1
Bench Space
The nano pump dimensions and weight (see Table 1) allow to place the nano
pump on almost any laboratory bench. It needs an additional 2.5 cm
(1.0 inches) of space on either side and approximately 8 cm (3.1 inches) in the
rear for the circulation of air and electric connections.
If the bench should carry a complete Agilent 1100 Series system, make sure
that the bench is designed to carry the weight of all the modules.
Environment
Your nano pump will work within specifications at ambient temperatures and
relative humidity as described in Table 1.
Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
The pump should be operated in a horizontal position!
Do not store, ship or use your nano pump under conditions where temperature
fluctuations could cause condensation within the nano pump. Condensation will
damage the system electronics. If your nano pump was shipped in cold weather, leave
it in its box and allow it to warm slowly to room temperature to avoid condensation.
Table 1 Physical Specifications
Type Specification Comments
Weight 17 kg (39 lbs)
Dimensions
(height × weight × depth)
180 × 345× 435 mm
(7 × 13.5× 17 inches)
Line voltage 100 – 120 or 220 – 240VAC, ± 10 % Wide-ranging capability
