Agilent Technologies 1100 Series - Power and Status Light Pipes

1100 Series Nano Pump Service Manual 167
Parts and Materials 4
Power and Status Light Pipes
Table 21 Power and Status Light Pipes
Item Description Part Number
1 Light pipe —power switch 5041-8382
2 Power switch coupler 5041-8383
3 Light pipe — status lamp 5041-8384
4 Power switch button 5041-8381
Figure 31 Power and Status Light Pipes
1
2
3
4
