1100 Series Nano Pump Service Manual 113
Repairing the Pump 3
7 Reinstall the outlet ball valve and tighten the valve.
8 Reconnect the valve capillary.
Figure 16 Outlet Ball Valve Parts
Figure 17 Exchanging the Outlet Ball Valve
Valve body
Gold seal
Plastic cap
Sieve
Valve capillary
Outlet ball valve
