6 1100 Series Nano Pump Service Manual
1 Installing the Pump
Wrench open end 1/4 - 5/16 inch (x1) 8710-0510
Wrench open end 14mm (x 1) 8710-1924
Wrench open end 4 mm, (x 1) 8710-1534
Hex key 2.5 mm, 15cm long, straight handle (x 1) 8710-2412
Hex key 3.0 mm, 12cm long (x 1) 8710-2411
Hex key 4.0 mm, 15cm long, T handle (x 1) 8710-2392
Torque adapter G1315-45003
CAN cable (1 m long) 5181-1519
Purge valve assembly G1311-60009
Purge valve holder G1312-23200
Screw for the purge valve holder 0515-0175
FS to Inj valve cap. (350 mm, 25 µm) G1375-87322
FS to Inj valve cap. (550 mm, 25 µm) G1375-87323
Flow sensor accuracy calibration capillary (8000 mm, 25 µm) G2226-67300
ESD wrist strap 9300-1408
Table 2 Nano Pump Accessory Kit Content G2226-68705, continued
Description Part Number
