Alcatel-Lucent OpenTouch R1.x Troubleshooting guide
Ed.15 / June 2013
163/182
TG0064
2. Select Trunks Group/ Descend hierarchy/Trunk Group/ Review/Modify
Check that:
End to End dialing = no
DTMF End to End dialing = no
3. Select SIP/SIP Gateway/Review/Modify
┌─Review/Modify: SIP Gateway─────────────────┐
│ │
│ Node Number (reserved) : 101 │
│ Instance (reserved) : 1 │
│ │
│ SIP Subnetwork : <RN_ID> │
│ SIP Trunk Group : <SIP_TG_ID> │
│ SIP Subscribe Min Duration : 600 │
│ DNS local domain name : <mydomain.com> │
│ DNS type + DNS A │
│ SIP DNS1 IP Address : <DNS1 IP ADDR> │
│ SIP DNS2 IP Address : <DNS2 IP ADDR> │
└────────────────────────────────────────────┘
• Set the SIP Gateway sub network to the value entered for the trunk group <RN_ID>
• Associated the SIP Gateway with the created trunk group: <SIP_TG_ID>
• Enter the DNS local domain name.
• Enter the DNS Server IP address (needed for survivability)
4. Select SIP/SIP External Gateway/Create
┌─ Create : SIP Ext Gateway ────────────────┐
│ │
│ Node Number (reserved) : 101 │
│ SIP External Gateway ID : <EXT_GW_ID> │
│ │
│ Gateway Name : To ESS │
│ SIP Remote domain : <ICE FQDN> │
│ SIP Port Number : 5260 │
│ SIP Transport Type + TCP │
│ Belonging Domain : “” │
│ │
│ Trunk group number : <SIP_TG_ID> │
│ SIP DNS1 IP Address : <DNS IP ADDR> │
│ Minimal authentication method + SIP None │
│ Ignore inactive/black hole + True │
│ Gateway type + ICE type │
└───────────────────────────────────────────┘
• Enter a unique ID for the SIP external gateway: <EXT_GW_ID>
• Enter a gateway name: “TO ESS”
• Enter the ICE FQDN for the remote SIP domain.
• Enter the ICE sip server port (ESS SipServer port) : MUST be 5260.
• Associate the created trunk group <SIP_TG_ID> to the external SIP gateway.
• Set Ignore inactive/black hole to True
21.4 Logs setting
21.4.1 To setup logs
1. The main process used on the oxe is SIPmotor.
To trace this process
