Alcatel-Lucent OpenTouch R1.x Troubleshooting guide

TG0064

86/182

Ed.15 / June 2013

13.3 Messages flow

On the OpenTouch server launch wireshark / edit / preferences / protocol: select SSL protocol

In RSA keys list : ICE_IP@,443,http,/usr/muxer/rsa.myice_FQDN.key.pem
