7.10 CAN bus / Testmodes 7 ADDITIONAL ITEMS: BEYOND BASIC FUEL AND IGNITION CONTROL
• Innovate Motorsports serial data is not supported directly, but you can connect an Innovate Motorsports serial
data chain to a CAN-EGT module or third party devices sold by JBPerf that translate this data into MS3Pro
29 bit CAN.
• AEM 4 channel and X series UEGO devices use their own AEMNet CAN format. If using an AEM external
wideband over CAN, you must disable all other 29 bit CAN functions such as interfacing with a MicroSquirt
transmission control or CAN-EGT module. 11 bit functions such as Racepak V-net adapters will still function.
• ECOTRONS widebands also use their own proprietary 29 bit CAN format and require disabling all other 29
bit CAN functions. You will need to set the CAN data rate to 250K instead of the usual 500K under CAN
Parameters to use an ECOTRONS wideband.
• Generic wideband receiving allows for receiving user defined messages over 11 bit CAN. You will need to
configure the device under the CAN Receiving screen to provide a value of lambda * 10000.
• JBPerf GPS modules.
• Race Technology devices that transmit GPS and accelerometer data.
JBPerf devices and other devices that use 29 bit MS-CAN require configuring the remote CAN ID, table, and offset
values. Race Technology devices require setting a base address. Consult your CAN device’s documentation for
details.
7.10.8 Real time clock
The MS3Pro has a built in clock that lets you apply a date stamp to data logs.
AMP EFI MS3Pro manual version 1.202, firmware 1.5.0, 4/21/2017 Page 265
