Vector Voltmeter, Option 15 11-6 Calibration Correction
Vector Network Analyzer MG PN: 10580-00289 Rev. K 11-7
1The VNAMaster
2 Optional Test Port Cable
3 OSL (Open, Short, Load) Precision Calibration Components
Figure 11-2. 1-Port Calibration, using MS2024B
1
2
3
OPEN
SHORT
LOAD
