1.1.2.7. MX882112C/13C-021
Table 1.1.2.7-1 LTE-Advanced FDD/TDD DL CA Measurement Software
The reception measurements for DL 2CCs and UL 1CC described in Chapter 7
of 3GPP TS 36.521-1 and the maximum throughput tests are supported.
The maximum throughput test for DL CA 2x2 MIMO is supported by using with
the MX882012C/13C -011 2x2 MIMO DL option.
Output frequency: 400 to 2700 MHz (1-Hz steps)
3400 to 3800 MHz
(Can be used when installing MT8821C-018 option)
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
1.1.2.8. MX882112C/13C-022
Table 1.1.2.8-1 LTE-Advanced FDD/TDD UL CA Measurement Software
This can be used to measure the functions and Tx/Rx performance of UEs at
2CCs UL CA.
Frequency 500 to 3800 MHz
3800 to 4200 MHz
(Can be used when installing MT8821C-019 option)
Same as MX882112C for CC measurements. The measurement target is only
PUSCH.
Same as MX882112C except measurement accuracy and linearity in CC
measurements. The measurement target is only PUSCH.
Measurement accuracy ±0.7 dB (–20 to +35 dBm)
±0.9 dB (–50 to –20 dBm)
500 MHz ≤ Freq. ≤ 3000 MHz
10° to 40°C after calibration
±1.0 dB (–50 to +35 dBm)
±1.3 dB (–60 to –50 dBm)
3000 MHz < Freq. ≤ 3800 MHz
10° to 40°C after calibration
±1.0 dB (–50 to +35 dBm),
±1.3 dB (–60 to –50 dBm),
3800 MHz < Freq. ≤ 4200 MHz,
20° to 30°C after calibration
(At Intraband Continuous CA SCC, PCC+SCC
measurement)
Linearity ±0.2 dB
(–40 to 0 dB, ≥–50 dBm, 20° to 30°C
after calibration),
±0.4 dB (–40 to 0 dB, ≥–60 dBm, 20° to 30°C
after calibration),
500 to 4200 MHz
