19
1.1.2.10. MX882112C/13C-031
Table 1.1.2.10-1 LTE-Advanced FDD/TDD DL CA 3CCs Measurement Software
Item
Specifications
Function
The reception measurements for DL 3CCs and UL 1CC, and the maximum
throughput tests are supported.
The maximum throughput test for DL CA 2x2 MIMO is supported by using with
the MX882012C/13C-011 LTE FDD/TDD 2x2 MIMO DL option.
RF Signal Generator
Output frequency: 400 to 3800 MHz (1-Hz steps)
400 to 6000 MHz
(Can be used when installing MT8821C-019 option)
Throughput
Measurement
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
1.1.2.11. MX882112C/13C-036
Table 1.1.2.11-1 LTE-Advanced FDD/TDD DL CA 3CCs IP Data Transfer
Item
Specifications
Function
At DL CA 3CCs, IP data transfer is supported by using the internal server of the
MT8821C, or IP data transfer with external devices is supported by using the
Ethernet port of the LTE measurement hardware.
1.1.2.12. MX882112C/13C-041
Table 1.1.2.12-1 LTE-Advanced FDD/TDD DL CA 4CCs Measurement Software
Item
Specifications
Function
The reception measurements for DL 4CCs and UL 1CC, and the maximum
throughput tests are supported.
The maximum throughput test for DL CA 2x2 MIMO is supported by using with
the MX882012C/13C-011 LTE FDD/TDD 2x2 MIMO DL option.
RF Signal Generator
Output frequency: 400 to 3800 MHz (1-Hz steps)
400 to 6000 MHz
(Can be used when installing MT8821C-019 option)
Throughput
Measurement
Function: Throughput measurement using RMC
Measurement target: ACK and NACK reported from UE
1.1.2.13. MX882112C/13C-046
Table 1.1.2.13-1 LTE-Advanced FDD/TDD DL CA 4CCs IP Data Transfer
Item
Specifications
Function
At DL CA 4CCs, IP data transfer is supported by using the internal server of the
MT8821C, or IP data transfer with external devices is supported by using the
Ethernet port of the LTE measurement hardware.
