1.1.2.14. MX882142C/43C (Non-Call Procsssing)
Table 1.1.2.14-1 Measurement Software Specifications (MX882042C/43C) (1/2)
Measurement Item
Specifications
Electrical
Typical values (typ.) are only for reference and are not guaranteed.
Frequency/Modulation
Measurement
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
Input level –40 to +35 dBm (Main1/2)
Carrier frequency
accuracy ±(Set frequency × Reference oscillator accuracy
+15 Hz)
Modulation accuracy
Residual vector error ≤2.5% (400 to 3800 MHz)
(When measurement count is 20)
≤3.5% (3800 to 5000 MHz)
(When measurement count is 20)
In-band Emissions ≤–40 dB
(≥–10 dBm, Allocated RB≤18)
Measurement object PUSCH
Amplitude
Measurement
Frequency 400 to 3800 MHz
3800 to 5000 MHz
(Can be used when installing MT8821C-019 option)
Input level –60 to +35 dBm (Main1/2)
Measurement accuracy ±0.5 dB (–20 to +35 dBm)
typ. ±0.3 dB (–20 to +35 dBm)
±0.7 dB (–50 to –20 dBm)
±0.9 dB (–60 to –50 dBm)
400 to 3800 MHz, 10° to 40°C after calibration
±0.7 dB (–20 to +35 dBm)
±0.9 dB (–50 to –20 dBm)
±1.1 dBv–60 to –50 dBm)
3800 to 5000 MHz, 10° to 40°C after calibration
Linearity ±0.2 dB (–40 to 0 dB, ≥–50 dBm)
±0.4 dB (–40 to 0 dB, ≥–60 dBm)
400 to 5000 MHz
Measurement object PUSCH
