22. [SCC] Execute PRESET to set default parameters.
23. [SCC] Execute CALLPROC OFF to set Call Processing to Off.
24. [SCC] Execute BANDWIDTH 20MHZ to set Channel Bandwidth to 20 MHz.
25. [SCC] Execute DLCHAN 498 to DL Channel to 498.
26. [SCC] Execute CHCODING PACKET_DL_CA_SCC to set Channel Coding to Packet (DL CA - SCC).
27. [SCC] Execute ANTCONFIG OPEN_LOOP to set Antenna Configuration to 2x2MIMO (Open Loop).
28. [SCC] Execute DLRB 100,0 to set DL RMC - Number of RB to 100, and DL RMC - Starting RB to 0.
29. [SCC] Execute DLIMCS1 28, DLIMCS2 28 and DLIMCS3 28 to set All of DL RMC - MCS Index(x) to 28.
30. [SCC] Execute BANDWIDTH_PCC 20MHZ to set PCC - Channel Bandwidth to 20 MHz.
31. [SCC] Execute ULCHAN_PCC 18300 to set PCC - UL Channel to 18300.
32. [SCC] Execute ULRMCRB_PCC 100 to set PCC - UL RMC - Number of RB to 100.
33. [SCC] Execute ULRB_START_PCC 0 to set PCC - UL RMC - Starting RB to 0.
34. [SCC] Execute ULIMCS_PCC 23 to set PCC - MCS Index to 23.
Note: The above five procedures are necessary to receive the uplink signal at the MT8820C SCC.
Set the same parameters as the MT8820C functioning as PCC.
MT8820C (PCC)
MT8820C (SCC)
Common Parameter - Channel Bandwidth
Call Processing Parameter - PCC - Channel
Bandwidth
Common Parameter - UL Channel
Call Processing Parameter - PCC - UL Channel
Common Parameter - UL RMC - Number of RB
Call Processing Parameter - PCC - UL RMC
Number of RB
Common Parameter - UL RMC - Starting RB
Call Processing Parameter - PCC - UL RMC
Starting RB
Common Parameter - UL RMC - MCS Index
Call Processing Parameter - PCC - UL RMC
MCS Index
35. [SCC] Execute SERVERIP 192,168,20,10 to set Server IP Address to 192.168.20.10.
36. [SCC] Execute CLIENTIP 192,168,20,11 to set Client IP Address to 192.168.20.11.
37. [SCC] Execute CLIENTIP2 192,168,20,12 to set Client IP Address 2 to 192.168.20.12.
38. [SCC] Execute DEDEPSACT ON to set Dedicated EPS Bearer Activation to On.
39. [SCC] Execute LINKEPSID 5 to set Linked EPS Bearer Identity to 5. (Note 2)
40. [SCC] Execute TFTIPV4 192.168.20.100 to set TFT Remote IPv4 Address to 192.168.20.100.
41. [SCC] Execute CALLSO to reset the internal configuration of the MT8820C SCC.
Note 1: Execute this procedure to ensure IP Data communication on the MT8820C SCC.
Note 2: Some UEs may request establishment of the second Default EPS Bearer by conveying a PDN
Connectivity Request message after checking the Connected state. To verify IP data communication with
this UE and communicate to the second EPS Bearer, execute following procedure instead of step19 and step
38.
19. [PCC] Execute LINKEPSID 6 to set Linked EPS Bearer Identity to 6.
38. [SCC] Execute LINKEPSID 6 to set Linked EPS Bearer Identity to 6.
The Dedicated EPS Bearer will be linked to the second Default EPS Bearer by these settings. The SCC using
the dedicated EPS Bearer as the IP data path will communicate with the second Default EPS Bearer's IP
address (Call Processing Parameter - Client IP Address2).
[Example of IP Data Path when Linked EPS Bearer Identity Set to 6]
The SCC can communicate with the second EPS Bearer’s IP address (Call Processing Parameter - Client IP
Address2).
