AX-4030
2-47
AUTION MAX AX-4030 OPERATING MANUAL
5 Press Start to start check measurement.
• When check measurement is completed, the
obtained result will be reported on the screen.
6 Press Print to print the result.
7 Evaluate the check measurement results.
1 Check the two printed result reports to see if the obtained reflectivity of each wavelength falls
within the range listed on the container label.
REFERENCE: For information on the result reports of check measurement, see “2.8.6 Check
Measurement Result Report” on page 2-56.
When the results are:
Within range
The instrument is working normally. Go to step
9 .
Out of range
Either the instrument or the test strips are abnormal. Perform a check measurement again. Press
Go back to return to the [Maintenance] screen. Take the remaining two check strips out of the
container, and repeat from step 2 - 4 on page 2-44. Go to step 8 when completed.
NOTE: If the printed results report includes an error message, clear the error as follows.
Reflection light intensity drift: Internal measurement operation is interfered by lights coming
from outside of the instrument. Remove the cause, and use the
same check strips to retry check measurement.
Test strip out-of-position: The check strip is out of position. Use the same check strips to
retry check measurement.
To Next Page
