ARM Cortex A9 User Manual

Functional Description
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 2-14
ID073015 Non-Confidential
Figure 2-4 Power domains for the Cortex-A9 processor
The FPU is part of the processor power domain. The FPU clock is based on the processor clock.
There is static and dynamic high-level clock-gating. NEON SIMD data paths and logic are in a
separate power domain, with dedicated clock and reset signals. There is static and dynamic
high-level clock-gating.
When NEON is present, you can run FPU (non-SIMD) code without powering the SIMD part
or clocking the SIMD part.
Core0
NEON
SIMD
CPU0 logic + FPU +
Shared FPU/MPE logic
and register file
Clamp
Vmpe0
Vcpu0
Clamp
CPU0
RAMS
Vram0
Clamp/
Level shifter

ARM Cortex A9 Specifications

General

Architecture	ARMv7-A
Cores	1-4
SIMD Extensions	NEON
ISA	ARM
Microarchitecture	Cortex-A9
Instruction Width	32-bit
Data Width	32-bit
MMU	Yes
Instruction Set	ARMv7-A
Clock Speed	Up to 2 GHz
L1 Cache	32 KB Instruction, 32 KB Data (per core)
Process Technology	40 nm, 28 nm
Floating Point Unit	VFPv3
Pipeline Depth	8 stages
Power Consumption	Low power design
